MAGNESIUM OXIDE BOARD
Magnesium Sulphate Board Is A New Generation Board Of Magnesium Oxide Board Which Is Also Called Mgso4 Board. It Is Made Of Pure Magnesium Oxide And Magnesium Sulphate，Reinforced By Strong Alkali Free Glass Fiber Mesh.
Mgso4 board uses magnesium sulfate instead of magnesium chloride. magnesium sulfate makes Mgso4 panels incredibly waterproof by preventing moisture from absorbing back into the halogens in the board.
It made from magnesium oxide (Mgo), magnesium sulfate (Mgso4), bamboo filler and reinforced by fiber glass mesh.
• Strong, durable and very easy to work with regular wood working tools.
• Dimensionally stable, factory sealed and T&G on long edges or square.
| Thickness | Size | Density | Color | Edges |
| 3 | 1220*2440MM, 1220*2745MM, 1220*3050MM Other Sizes can be customized | 900-1400Kg/M3 | Off-White, Grey, Black, Yellow. | Square |
| 4 | Square | |||
| 5 | Square | |||
| 6 | Square | |||
| 8 | Square | |||
| 9 | Square | |||
| 10 | Square | |||
| 12 | Square,Tapered | |||
| 15 | Square,Tapered | |||
| 16 | Square,Tapered,T&G,Shiplap | |||
| 18 | Square,Tapered,T&G,Shiplap | |||
| 20 | Square,Tapered,T&G,Shiplap | |||
| 25 | Square,Tapered,T&G,Shiplap | |||
| 30 | Square,Tapered,T&G,Shiplap |
| Thickness | Size | Edges | Desnity | Color |
| 16 | 600*2700mm 1220*2440mm | Square, T&G, Shiplap | 1.15kgs/m3 | Off-White, Grey, Black, |
| 18 | ||||
| 19 | ||||
| 20 |
Mgso4 board is a versatile and highly customized product. Depending on using areas, the
formulation can be changed to achieve different physical properties of strength, water resistance,
and rigidity.It can also make different surface treatments such as polishing, slurrying and brushing.
We strive to explore all possibilities of MGO applications in construction industry.
Mgo board is mainly made of magnesium oxide, mgso4 replace of mgcl2, fiber glass mesh and wood
fiber.it is an ideal material used as ceiling and interior wall, when adding waterproof formula, it can
be well used as a baseboard for exterior walls and other high moisture areas.
Fire rated board including Mgo board and Mgo perlite board. with thickness from 3mm to
50mm, can be applied in every part of a fire door.
Sanded mgo board surface treatments can be varied, such as sanding and polishing, which made board smoother and flatter, the thickness is more accurate which is suitable for lamination with PVC
film,HPL sheet and paper.
It made from magnesium oxide (Mgo), magnesium sulfate (Mgso4),
1.What is Jiafeng mgo board made of? What is the chloride content?
All mgo board consists of 3 elements, magnesium oxide, salt and crystal water.
The main component of Jiafeng Mgo board is magnesium oxide powder which is completely
non-flammable and can be used for fire protection.
2. Is Jiafeng Mgo board waterproof?
Jiafeng Mgo board is considered to be moisture resistant, but during prolonged exposure,
moisture can affect properties and it will experience hydrothermal expansion. When used outdoors,
Mgo board should be covered or coated to protect it from the environments, we can do waterproofing before leaving the factory according to customer needs, such as adding waterproofing elements
in composition or sealing with UV paint. Normal mgo board water absorption is around 20%. Waterproof mgo board waterproof meet less than 10% of water absorption.
3.What is the difference between Jiafeng mgo board and other mgo boards?
◆Jiafeng is new generation chloride free mgo board. Thickness 3-30mm.Max size 1220*3050mm.
◆We are ICC Audit factory, Controlled from Raw materials to finished products are strictly
inspected.
◆Jiafeng mgo board has outstanding physical performance
Standard strength 6mm> 20-35 Mpa, 12mm > 15– 20Mpa,18mm≥20-25Mpa.
●Minimum low water absorption rate <8-10%
●Chloride Content ≤0.012%
●Fire resistance up to 270mins.
4. Is Jiafeng Mgo Board safe product?
Yes. Jiafeng Mgo board is safer than many comparable building products. It is a mineral based product made with non-toxic ingredients. (See our test report of Asbestos content, TOVC) It is
completely recyclable and resistant to mold, mildew, fungus and allergens. It is also free of carcinogens and silicas
Magnesium Sulphate Board Is A New Generation Board Of Magnesium Oxide Board Which Is Also Called Mgso4 Board
Magnesium Sulphate Board Is A New Generation Board Of Magnesium Oxide Board Which Is Also Called Mgso4 Board
Sanded mgo board surface treatments can be varied, such as sanding and polishing, which made board smoother and flatter, the thickness is more accurate which is suitable for lamination with PVC film
Lightweight mgo board is using eps particles to replace wood chips, which can make itself more lightweight and in a lower density
Structural mgo sheathing is made from compressed magnesium oxysulfate by unique formula design.
